SICK CLV6 Series - Ordering information; Dimensional drawings (Dimensions in mm (inch))

CLV6 SERIES | SICK8016144/2013-09-19
Subject to change without notice
53
BAR CODE SCANNERS CLV65x
Ordering information
• Focus: Auto focus
• Scanner design: Line scanner
• Heating: optional
• Front screen: Glass
Version Connection type Reading eld Model name Part no.
CLV650 Standard Density
Cable
Front CLV650-0000 1041290
Oscillating mirror CLV650-6000 1042124
Ethernet
Front CLV650-0120 1042121
Oscillating mirror CLV650-6120 1042125
CLV651 Low Density
Cable
Front CLV651-0000 1046557
Oscillating mirror CLV651-6000 1046559
Ethernet
Front CLV651-0120 1046558
Oscillating mirror CLV651-6120 1046560
Dimensional drawings (Dimensions in mm (inch))
CLV63x/64x/65x Standard, front
CLV63x/64x/65x Standard, oscillating mirror
