BAR CODE SCANNERS CLV69x
Detailed technical data
Features
CLV690 -0/1 Standard
Density
CLV691-0/1 Low Density CLV692- 0/1 High Density
No. of distance congurations
≤ 8
Focus adjustment time
≤ 20 ms
Focus trigger source
Data interface / switching inputs
Light source
Visible red light (660 nm)
MTBF
100,000 h
Laser class
2 (IEC 60825-1 (2007-3), EN 60825-1 (2008-05))
Field of view
Front ≤ 60°
Oscillating mirror ≤ 50°
Scanning frequency
400 Hz ... 1,200 Hz
Code resolution
0.25 mm ... 1 mm 0.35 mm ... 1.2 mm 0.17 mm ... 0.4 mm
Reading distance (at code resolution)
500 mm ... 2,100 mm
(0.5 mm)
500 mm ... 2,200 mm
(0.5 mm)
400 mm ... 1,600 mm
(0.3 mm)
Oscillating mirror functions
Fixed (adjustable position), oscillating (variable or xed amplitude), one shot
Oscillation frequency 0.5 Hz ... 4 Hz
Angle of deection –20° ... 20° (can be adjusted via software)
Performance
Bar code types
Interleaved 2 of 5, all current code types, Codabar, Code 128, Code 39, Code 93,
GS1-128 / EAN 128, UPC / GTIN / EAN, Pharmacode
Print ratio
2:1 ... 3:1
No. of codes per scan
1 ... 20 (Standard decoder)
1 ... 6 (SMART decoder)
No. of codes per reading interval
1 ... 50 (auto-discriminating)
No. of characters per reading interval
5,000
No. of multiple readings
1 ... 100
Interfaces
Ethernet
l, only with cloning plug I/O Ethernet
Function Host, AUX
Data transmission rate 10/100 Mbit
Protocol TCP/IP, EtherNet/IP, PROFINET (optional via external connection module CDF600-2),
PROFINET Dual Port (optional via external connection module CDF600-2)
CAN bus
l
Function SICK CAN sensor network (Master/Slave, Multiplexer/Server)
Data transmission rate 20 kbit/s ... 1 Mbit/s
Protocol CSN (SICK CAN Sensor Network)
PROFIBUS DP
l, optional via external connection module (CDF600-2)
DeviceNet
l, optional via external connection module (CDM + CMF)
Switching inputs
6 (“Sensor 1” ... “Sensor 6”)
Switching outputs
4 (“Result 1” ... “Result 4”)
A
B
C
D
E
F
H
I
J
K
L
M
N
O
P
Q
R
S
T
