SICK CLV6 Series User Manual

CLV6 SERIES | SICK 8016144/2013-09-19
Subject to change without notice
60
CLV69x BAR CODE SCANNERS
Reading pulse
Switching inputs, serial interface, auto pulse, CAN
Optical indicators
6 LEDs (Ready, Result, laser, Data, CAN, LNK TX, Bar graph for displaying the reading rate
percentage (10 LEDs))
Control elements
2 buttons
Parameter storage
Integrated in cloning plug
Mechanics/electronics
CLV690 -0/1 Standard
Density
CLV691-0/1 Low Density CLV692- 0/1 High Density
Electrical connection
Depending on the cloning plug used
Operating voltage
18 V DC ... 30 V DC
Power consumption
15 W / 17 W (depending on type)
Housing
Die-cast aluminum
Housing color
Light blue (RAL 5012)
Enclosure rating
IP 65 (IEC 60529 (1989-11))
Protection class
III (EN 60950-1 (2011-01))
Weight
1,500 g / 2,200 g (depending on type)
Dimensions
Front 117 mm x 117 mm x 94 mm
Oscillating mirror 182 mm x 128 mm x 97 mm
Ambient data
Vibration resistance
EN 60068-2-6 (2008-02)
Shock resistance
EN 60068-2-27 (2009-05)
Electrical safety
EN 60950-1 (2006-01) / EN 60950-1/A11 (2009-03) / EN 60950-1/A1 (2010)
Ambient operating temperature
0 °C ... +40 °C
Storage temperature
–20 °C ... +70 °C
Permissible relative humidity
90 %, non-condensing
Ambient light safety
2,000 lx, on bar code
Ordering information
• Focus: Auto focus
• Connection type: depending on the cloning plug used
• Scanner design: Line scanner
Version Reading eld Front screen Model name Part no.
CLV690-0/1 Standard Density
Front
Glass CLV690-0000 1056600
Plastic CLV690-0010 1056614
Oscillating mirror Glass CLV690-1000 1056601
CLV691-0/1 Low Density
Front Glass CLV691-0000 1056604
Oscillating mirror Glass CLV691-1000 1056605
CLV692-0/1 High Density
Front Glass CLV692-0000 1056608
Oscillating mirror Glass CLV692-1000 1056609
