Chapter 4 Technical Information
CLV61x bar code scanner
50 © SICK AG · Germany · All rights reserved · Subject to change without notice 8015592/ZNI9/2017-06-13
Electrical installation
4.8.12 Wiring the "External output 2" Switching Output in the CDM420-0001 Connec-
tion Module
The CLV61x indicates the switching status of its
logical "external output 2" via the serial Aux data
interface.
Software-controlled, the status is automatically
taken over by the CMC600 via the cable and
converted to the physical "Aux Out 2" output in
the CDM420-0001.
Load (e.g. PLC)
GND
Quenching circuit:
Install an anti-surge
diode directly at the
load!
For inductive load:
V
out
Ratings for "External output 2" ("Aux Out 2" switching output)
PNP switching against the supply voltage V
S
(+24 V*)
(default setting: no function/disabled,
logic: not inverted [active high])
– Short-circuit proof + temperature protected
– Galvanically not separated from V
S
(+24 V*)
0 V ≤ V
out
≤ V
S
Guaranteed:
(V
S
−1.5 V) ≤ V
out
≤ V
S
with I
out
≤ 100 mA
Switching
behavior
Features
Electrical
values
CLV61x
Serial Aux
(RS-232)
CDM420-0001
V
S
= DC 10 V to 30 V
CMC600
+24 V* (V
S
)
30
Aux Out 2
26
GND
6
Shield
"External
output 2"
