SICK CLV61 Series Technical Information

Technical Information Chapter 3
CLV61x
Mounting
8015592/ZNI9/2017-06-13 © SICK AG · Germany · All rights reserved · Subject to change without notice 11
3 Mounting
3.1 Notes on Mounting
 The permitted ambient conditions for the operation of the CLV61x must be complied
with e.g., temperature, radiated emission, ground potential in situ.
See "CLV61x bar code scanner" operating instructions (no. 8015589)
 The device must only be mounted to the optional SICK brackets using the pairs of
threaded mounting holes provided for this purpose.
3.2 Optional Accessories
For fastening the CLV61x directly to a mounting device (base) 4 SICK brackets in all are
available (see the following pages).
Brackets for optional Mirror Hood No. 2046811
Views and dimensions of the two corresponding brackets no. 2048633 and no. 2046822
for the CLV6xx optional mirror hood are shown in the fitting instructions for "External mirror
hood for bar code scanners of the CLV6xx family " (no. 8013180, Ger./Engl. version).
