(19)
(3.5)
10
11
4
(AF3)
38
10
48
16
22
10
19
(M5)
(Ø 7.5)
2
1
(SW3)
1
2
Quick release clamp
no. 2025526 (parts 1 and 2),
can be adjusted in 90°-steps
Bracket no. 2020410,
each angle leg adjustable in 90°
steps. Here shown as supplement.
Included to fix the bar code scanner to the quick release clamp:
2 x cylinder head screws M5 x 8, with hexagon socket (AF3), self-locking
M5, screw-in depth max. 8 mm
All length measures in mm
Mounting sample
(Bracket no. 2020410
not included in delivery
of quick release clamp)
