SICK CLV61 Series Technical Information

Technical Information Chapter 3
CLV61x
Mounting
8015592/ZNI9/2017-06-13 © SICK AG · Germany · All rights reserved · Subject to change without notice 13
3.2.2 Dimensional Drawing of Bracket No. 2020410
Included to fix the bar code scanner to the bracket:
2 x cylinder head screws M5 x 8, with hexagon socket (AF3), self-locking
43
60
4
90°
36.5
27
18
18.7
9.7
3.8
5.2
14
Elongated hole:
5.2
large:
small:
18
18.7
9.719.5
Mounting sample
All length measures in mm
Angle leg
adjustable in
90°steps
