SICK FX3-MOC1 - 12.3 Data sheet

Digital outputs (A1) from station B
T
able 117: Example for the calculation of the response time for the digital inputs (E1) from
station B
General information Response time of the actuator 40.0 ms
General information Output processing time 4.5 ms
Total A1 44.5 ms
Total response time of station B
T
able 118: Example for the calculation of the total response time of station B (remote input to
local output) in a Flexi Link system
1. Inputs Response time of the input
under c
onsideration on the
signal path
E2 19.0 ms
2. Logic Logic response time 2 × logic execution time 16.0 ms
Delay due to logic application –
3. Outputs Response time of the output
under c
onsideration on the
signal path
A1 44.5 ms
Total response time (remote input to local output) of station B 79.5 ms
12.3 Data sheet
12.3.1 Main modules CPU0, CPU1, CPU2 and CPU3
Safety-related parameters
T
he data apply to an ambient temperature of +40°C.
Table 119: Safety-related parameters CPUx
CPU0 CPU1/2/3
Safety integrity level (IEC61508)
S
afety integrity level (IEC62061)
SIL 3
Category(ISO13849) Category 4
Performance level (ISO13849) PLe
PFH
D
1.07 × 10
–9
1.69 × 10
–9
PFH
D
f
or Flexi-Line station
1)
– 0.40 × 10
–9
PFD
a
vg
5 × 10
–5
PFD
a
vg
for Flexi-Line station
1)
– 5 × 10
–5
T
M
(mis
sion time, ISO13849) 20 years
1)
Valid for a FX3-CPU3 main module which is only used for the transfer of information via Flexi Line.
General data
T
able 120: General data CPUx
CPU0, CPU1, CPU2, CPU3
Protection class (IEC61140) III
Immunity to interference EN 61000-6-2
Emitted interference EN 61000-6-4
TECHNICAL DATA 12
