STIO
Response time Depending on the logic configuration, for details see:
see
table 97, page 132
1)
In the event of an error (GND line open circuit) and with a load resistance of at least 2.5kΩ, no more than
t
he specified leakage current flows on the output. For lower load resistances, the leakage current may be
greater; however, the output voltage will be <5V in this case. A downstream device, for example a relay
or a FPLC (fail-safe programmable logic controller) must detect this state as Low.
2)
Example of resulting maximum coil induction: 2,960mH @ 0.5A.
Mechanical data
T
able 155: Mechanical data STIO
STIO
Dimensions (W × H × D) 22.5mm × 96.5mm × 120.6mm
Weight 139g (±5%)
Ambient data
T
able 156: Ambient data STIO
STIO
Enclosure rating (IEC60529) IP20
Ambient operating temperature
(UL/C
SA: surrounding air tempera‐
ture)
-25 ... +55°C
Storage temperature -25 ... +70°C
Air humidity ≤95%, non-condensing
Operating altitude Max. 2,000m above sea level (80kPa)
Vibration resistance 5–150Hz/1G (EN60068-2-6)
10–500Hz/3G
r
ms
(EN60068-2-64)
Shock resistance, continuous shock 15g, 11ms (EN 60068-2-27)
Shock resistance, single shock 30g, 11ms (EN 60068-2-27)
12.3.6 Analog input module ANA0
Safety-related parameters
T
he data apply to an ambient temperature of +40°C.
Table 157: Safety-related parameters ANA0
ANA0
Safety integrity level (IEC61508)
Safety integrity level (IEC62061)
SIL 3
Category(ISO13849) Category 4
Performance level (ISO13849) PLe
PFH
D
0.166× 10
–9
PFD
a
vg
2.5× 10
–5
T
M
(mis
sion time, ISO13849) 20 years
ANA0 general data
T
able 158: ANA0 general data
ANA0
Protection class (IEC61140) III
12 TECHNICAL DATA
152
O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller 8012478/1IG6/2023-02-24 | SICK
Subject to change without notice
