14 Accessories
14.1 Accessories for the safety controller
Table 197: Accessories for the safety controller
Part Type code Part number
Plug-in spring terminals – 2045890
Plug-in screw terminals – 2045891
EFI cable thin, 6.9 mm, PVC, sold by the meter – 6030921
Flexi Line cable, shielded, twisted pair, PVC,
2×0.22mm²
(AWG23), sold by the meter
– 6029448
Flexi Link cable, shielded, twisted pair,
2×2×0.34mm² (AWG22), sold by the meter
– 6034249
Configuration cable
2 m, M8, D
-Sub
– 6021195
Configuration cable
3 m, U
SB-A, USB Mini-B
– 6042517
Configuration cable
3 m, M8, an
gled, open end
– 6036342
Configuration cable, M8 on USB-A, 2 m DSL-8U04G02M025KM1 6034574
Configuration cable, M8 on USB-A, 10 m DSL-8U04G10M025KM1 6034575
14.2 Accessories for the motion control module
Encoder/motor feedback connection units
T
able 198: Encoder/motor feedback connection unit
Part Protective
c
oating
1)
Type code Part number
Facility for connecting two encoder/motor
feedback systems
Connection to the FX3-MOCx motion con‐
trol module: D-sub, female connector, 15-
pin
No FX3-EBX1 2079867
Facility for connecting one encoder/motor
f
eedback system
Connection to the FX3-MOCx motion con‐
trol module: D-sub, female connector, 15-
pin
Connection for additional encoder/motor
feedback connection units: D-sub, female
connector, 9-pin
No FX3-EBX3 2068728
Facility for connecting two encoder/motor
f
eedback systems
Connection to the FX3-MOCx motion con‐
trol module: D-sub, female connector, 15-
pin and HD D-sub, female connector, 15-
pin
No FX3-EBX4 2068729
Yes FX3-EBX400012 2117330
1)
For more challenging ambient conditions (e.g., resistance to sulfur).
