Inspector850
Feedback LED Optional e.g., variant of the VI83I illumination unit
2 LEDs:
•
Visible green light (λ = 525nm ±15nm)
•
Visible red light (λ = 645nm ±15nm)
Laser alignment
aid
1 laser, can be switched off
Visible red light (λ = 630nm ... 680nm)
Laser class Laser alignment aid:
Class 1 Laser Product according to EN/IEC 60825-1: 2014. Complies with
21CFR1040.10/11 except for conformance with IEC60825-1 Ed.3., as
described in Laser Notice No.56 dated 8May2019.
P <1.40mW
Lens C-mount
Order separately as an accessory
Optical format:
•
V2D8505x–xxxxxxxxxx: 1/1.8"
•
V2D8512x–xxxxxxxxxx: 1/1.1"
1)
Not yet available in pre-installed Quality Inspection SensorApp.
2)
Depends on lens used.
3)
L
B
= Hazard from blue light.
4)
L
R
= Hazard to the retina of the eye due to heating.
11.2 Mechanics and electronics
Inspector850
Connection type
•
1 male connector, M12, 17-pin, A-coded (Power, I/O)
1)
•
1 female connector, M12, 5-pin, A-coded (External illumination)
2)
•
1 female connector, M12, 8-pin, X-coded (GB Ethernet)
•
2 female connectors, M12, 4-pin, A-coded (Fieldbus Ethernet)
Supply voltage V
S
DC 24V ±20%
Voltage source in accordance with ES1 (EN62368-1) or SELV (EN60950-1)
Power consump‐
tion
Operation: 24W ±20% typical
3)
Current con‐
sumption
Max. 2.0A
Output current Sum of output currents: max. 400 mA
4)
Housingmaterial Aluminum die cast
Housing color Anthracite gray (RAL7016)
Viewing window
material
Glass or plastic (PMMA), 2mm thick, with scratch-proof coating
Cover (top of
device)
Material: Rubber
Function: For temporary access to the microSD memory card slot and the
USB connection
Hinged
5)
, screws (SW2 hexagon key), captive
Enclosure rating IP 65 (IEC60529:2013 +C1:2013 +C2:2015 +AMD2 C1:2019,
EN60529:1991 +A1:2010 +A2:2013 +AC:2019-02)
6)
Electrical safety EN 61010-1:2010
EN 61010-1:2010/A1:2019
EN 61010-1:2010/A1:2019/AC:2019-04
Weight Max. 640g, without lens and connecting cables
11 TECHNICAL DATA
