SICK Lector621 User Manual

Position Description Characteristic
11 Parameter set L: Limited Feature Set for variant Lector621
ECO
F: Full Feature Set for variant Lector621
12 Focal length B: 9.6 mm
F: 17, 1 mm
G: 17, 1 mm with visible block filter
13 Connection package B: Ethernet, serial, CAN, I/O, USB, memory
card slot
C: Ethernet, serial, CAN, I/O, USB
D: Serial, CAN, I/O, USB, memory card slot
E: Serial, CAN, I/O, USB
14 Protection class 5: IP 65
1)
Front view
2)
IR = Infrared light
NOTE
Not all combinations are possible according to the type code. The available device vari‐
ants can be found online at:
•
www.sick.com/Lector62x
3.1.2.1 Device variants
The Lector621 product family consists of two variant lines:
•
Lector621
•
Lector621 ECO
The two variant lines differ with respect to the following features:
Feature Lector621 Lector621 ECO
Integrated illumination unit 4 LEDs, colors type-dependent 2 LEDs, visible red light
Focus setting Teach auto focus Manual with SOPAS ET configu‐
ration software
Laser alignment aid Yes No
Additional evaluation DPM, OCR/OCV type-depen‐
dent
Not applicable
Focal length Depending on type 9.6 mm
Image recording rate (with
1.3 Mpx)
50 Hz 25 Hz
Readable code structures 1D, 2D, stacked codes. Type-
dependent: DPM, OCR/OCV
1D, 2D, stacked codes
Code quality determination Yes No
Shutter time ≥100 μs ≥200 μs
Slot for microSD memory
card
Yes No
Automatic parameter switch‐
ing
Yes No
PRODUCT DESCRIPTION 3
8022502/15NT/2020-02-11 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector621
13
Subject to change without notice
