11.2 Mechanics/electronics
Table 23: Technical data: Mechanics/electronics
Lector621 Lector621 ECO
Electrical connection 1 male connector, M12, 17-pin, A-
coded
1)
1 female connector, M12, 4-pin,
D-coded
1)
1 female connector, USB, 5-pin,
Micro-B type
1 microSD card slot
1 cable, length 0.9 m, with male
connector, D-Sub-HD, 15-pin
1 female connector, USB, 5-pin,
Micro-B type
Supply voltage V
S
DC 12 V ... 24 V, ± 20%
Voltage source as per ES1 and PS2 or lower (EN62368-1), or as per
SELV (EN60950-1)
Power consumption Operation: 4 W typical
2)
Maximum 22 W with typical load‐
ing of the 4 digital outputs with
100 mA each and 28.8 V DC sup‐
ply voltage
Operation: 4 W typical
2)
Maximum 16 W with typical load‐
ing of the two digital outputs with
100 mA each and 28.8 V DC sup‐
ply voltage
Current consumption Max. 1.7 A at 28.8 V DV Max. 0.6 A with DC 28.8 V
Housing material Die cast aluminum, plastic
Housing color Light blue (RAL 5012), black
Viewing window mate‐
rial
Plastic (PMMA), 2 mm thick, with scratch-proof coating
Hinged cover (rear of
device)
Material: Plastic
Function: for temporary access to the USB interface and memory card
slot (Lector621 only)
Hinged
3)
, 2 fixing screws, TX6, captive
Enclosure rating IP 65 (EN 60529, EN 60529/A2)
Protection class III
Electrical safety EN 62368-1
Weight 170 g 170 g
Dimensions
(L x W x H)
88.5 mm x 43 mm x 35.6 mm
5)
71 mm x 43 mm x 35.6 mm
5)
1)
On swivel connector.
2)
For digital outputs without load.
3)
When the cover is open, the device no longer conforms with the specified protection class.
4)
Devices without connecting cable.
5)
see "Device view", page 15.
11.3 Performance
Table 24: Technical data: Performance
Type Lector621 Lector621 ECO
Readable code structures 1D, 2D, stacked codes
Type-dependent: DPM,
OCR/OCV
1D, 2D, stacked codes
1D code types (bar code) GS1-128 / EAN 128, UPC / GTIN / EAN, Interleaved 2 of 5, Phar‐
macode, GS1 DataBar, Code 39, Code 128, Codabar, Code 32,
Code 93, Plessey Code, MSI/Plessey, Telepen
Postal codes Postnet, Planet, USPS 4SCB, Australia Post, Post Netherlands,
Royal Mail, Post Sweden
2D code types Data Matrix ECC200, GS1 Data Matrix, PDF417, PDF417 Trun‐
cated, QR-Code, MaxiCode
TECHNICAL DATA 11
8022502/15NT/2020-02-11 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector621
67
Subject to change without notice
