SICK Lector621 User Manual

6.5 Connecting the device
6.5.1 Using the optional connection modules CDB and CDM
Table 12: Possible combinations of device and connection modules
Device (variant) Connection on the
device
Connection module Connection cable
Lector621 Male connector, M12,
17-pin, A-coded
CDB650-204 Cable 1:1
1)
CDM420-0006
2)
Adapter cable
3)
Lector621 ECO Cable with male con‐
nector, D-Sub-HD, 15-
pin
CDB620
4)
–
CDM420
4)5)
1)
Connection cable 1:1 (female connector, M12, 17-pin, A-coded / male connector, M12, 17-pin, A-coded)
2)
CDM420-0007: for connection of 2 devices each.
3)
Adapter cable (female connector, M12, 17-pin, A-coded/male connector, D-Sub-HD, 15-pin)
4)
All variants of the connection module in each case.
5)
CDM420-0004 and CDM420-0007: for connection of 2 devices each.
NOTE
Connection module
For detailed information about mounting and electrical installation, please refer to the
operating instructions for the connection module in question. These are available
online at.
•
www.sick.com/CDB
•
www.sick.com/CDM
6.5.2 Connecting the supply voltage
Voltage source as per ES1 and PS2 or lower (EN62368-1), or as per SELV (EN60950-1).
The power source for the device must be able to provide the following power outputs:
Table 13: Required supply voltage V
S
Device variant Supply voltage V
S
Power source: required power out‐
put
1)
Lector621 DC 12 V ... 24 V ± 20% Maximum 25 W
Lector621 ECO DC 12 V ... 24 V ± 20% Maximum 18 W
1)
For device with 4 (2) loaded digital outputs (each 100 mA).
In the case of connection via the optional CDB or CDM connection module: additionally
required output power 0.5 W when using the optional CMC600 parameter cloning mod‐
ule in the connection module.
Table 14: Typical current consumption depending on supply voltage (Lector621)
Designation Supply voltage (V
S
) in [DC V]
9.6
(12 V -20%)
12 24 28.8
(24 V +20%)
Current consumption, digi‐
tal outputs unloaded
I
B RMS
[A] 0.4 0.32 0.17 0.14
Power loss, digital outputs
unloaded
P
RMS
[W] 3.84 3.84 4.08 4.03
Maximum current con‐
sumption, digital outputs
unloaded
I
B Peak
1)
[A] 1.05 0.90 0.45 0.35
ELECTRICAL INSTALLATION 6
8022502/15NT/2020-02-11 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector621
43
Subject to change without notice
