SICK Lector621 User Manual

Lector621 Lector621 ECO
EtherCAT® Protocol: EtherCAT®
Function: host (RS-232, data output of the read result)
Type of fieldbus integration: optionally via external CDF600-0300
fieldbus module
3)
(gateway mode) to bus (Ethernet)
Digital inputs Type: 2 physical, switching (“Sensor 1”, “Sensor 2”)
Optional 2 additional external logical inputs (software-controlled)
via the CMC600 parameter cloning module
3)
in the CDB
3)
or
CDM
3)
connection module
V
in
4)
= max. 30 V, I
in
5)
= max. 5 mA
Opto-decoupled, reverse polarity protected, adjustable debounce
time
6)
Digital outputs Type: 4 physical, switching
(“Result1”, “Result2”,
“Result3”, “Result4”)
When using the CDB420: 2
physical, switching (“Result1”,
“Result2”)
Type: 2 physical, switching
(“Result1”, “Result2”)
Optional 2 additional external logical outputs (software-controlled)
via the CMC600 parameter cloning module
3)
in the CDB
3)
or
CDM
3)
connection module
V
out
7)
= V
S
8)
– 1.5 V, I
out
9)
≤ 100 mA (typical)
Short-circuit protected, not electrically isolated from the supply
voltage
Reading pulse Digital inputs, free, serial interface, CAN, auto pulse, presentation
mode
Visual displays 5 status LEDs on the top side of the device
10 bar graph LED (blue) on the top side of the device
1 feedback LED (green) as light area on code
1 status LED (status indicator
for the memory card), under
hinged cover
–
Acoustic indicator Beeper (buzzer), can be switched off
6)
Function for event signaling and volume adjustable
6)
Operating elements 2 function buttons (select and start/stop functions)
Configuration tools (para‐
meterization)
SOPAS ET configuration software, web server, CoLa commands
(telegrams), fieldbus controller (PLC) with additional support by
SICK function blocks, function buttons
MicroSD memory card Micro SD memory card (flash card) max. 32 GB, optional
Data storage and retrieval image and data storage via microSD memory card and external
FTP
1)
For example: Configuration, diagnosis, transponder access or display of the read result.
2)
Data interface only for temporary use (service).
3)
Optional accessories.
4)
Input voltage.
5)
Input current.
6)
e.g. with SOPAS ET configuration software.
7)
Output voltage.
8)
Supply voltage.
9)
Output current.
TECHNICAL DATA 11
8022502/15NT/2020-02-11 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector621
69
Subject to change without notice
