Measurement status
Toolbar
Save permanently
Open login window
Change user interface language
Device menu
Navigation
1. Click on the desired menu.
✓
The workspace changes depending on the selected menu.
7.1.3 Navigating in the live image
Overview
The view of the scan data In SOPASair can be adjusted using the computer mouse.
Using the computer mouse
Function Computer mouse
Zoom in and zoom out Using the scroll wheel
Rotate view Left mouse button
Tilt view Right mouse button
7.1.4 User levels
The device has different user levels.
The user levels have different authorizations for configuring the device.
The current user level is displayed in the Log in panel.
1.
Click on the
button.
✓
The Log in to device input screen opens.
2. Select user level(User level), enter a password(Password) then click Login in.
User levels Password User and authorizations
Maintenance main Customers: Display only, no configu‐
ration
Authorized customer client Technical staff: Install and configure
device
Service service Service staff: Make advanced config‐
uration settings
NOTE
Change the passwords during initial commissioning to protect your device.
A higher user level can change the password of a lower user level.
COMMISSIONING 7
8027119/0000/2022-11 | SICK O P E R A T I N G I N S T R U C T I O N S | multiScan136
47
Subject to change without notice
