7.1.5 Displaying live data
1. In SOPASair: Open the user interface see "Opening user interface", page 46.
If no scan data are shown:
1. Click Configuration > Defaults.
2. Select Measuring.
7.1.5.1 Activating/deactivating filters
Prerequisites
•
You must be logged into the device see "User levels", page 47.
Selecting filters
1. Menu: Select Configuration > Default.
2. Activate or deactivate one or more filters.
Selecting the data reduction filter/region of interest filter
1. Menu: Select Application > Data output .
2. Activate or deactivate one or more filters.
7.1.6 Configuring interfaces
Settings for using the multifunctional I/Os can be configured in the Application > Inputs
and outputs menu. In addition, the current status and saved function of the input/output
are displayed.
The multifunctional I/Os are switchable and can therefore each be used as either a
digital input or output. The factory settings are as follows: multifunctional I/Os 1-4
preset as inputs and multifunctional I/Os 5-8 preset as outputs.
The inputs may switch on, switch off, and switch over analysis cases, for example. The
inputs can also be used to activate other functions, such as measurement data output
triggering.
The outputs can be used as digital switching outputs, for example to ground (PNP)
(depending on the device type). For each output, it is necessary to define whether it is
to be switched by means of SOPAS ET telegrams, or whether it is being used to signal
device readiness.
7.2 Operation in SOPAS ET
Execute the functions listed below via the SOPAS ET configuration software.
Functions
•
Install firmware updates
•
Import and export data
NOTE
To use the sensor with SOPASET, we recommend using port 2122 or port 80 in
SOPASET. When using the aforementioned ports, no limitation with regard to SOPASair
can be expected.
If a legacy protocol (CoLa A/B) is used on the ports 2111 and 2112, however, func‐
tional limitations in the SOPASET interface may arise.
The most up-to-date version of the SOPASET software can be downloaded from
www.sick.com/software, category: Configuration software, software type: SOPAS ET.
