10 Technical data
NOTE
The relevant online product page for your product, including technical data, dimensional
drawing, and connection diagrams, can be downloaded, saved, and printed from the
Internet.
The call is made via the SICK Product ID: pid.sick.com/{P/N}/{S/N}
{P/N} corresponds to the part number of the product, see type label.
{S/N} corresponds to the serial number of the product, see type label (if indicated).
Please note: This documentation may contain further technical data.
10.1 Features
Measurement principle Statistical measurement procedure
Application Indoor and outdoor
Light source Infrared (wavelength 850nm)
Laser class Laser class 1 (EN/IEC60825-1:2014, EN/IEC60825-1:2007)
Complies with 21 CFR1040.10 and 1040.11 except for conform‐
ance with IEC60825-1 Ed. 3 as described in Laser Notice No. 56,
dated May 8, 2019.
Horizontal aperture angle 360°
Vertical aperture angle 65° (+22. 5° to -42. 5°, DIN70000)
Scan field flatness High-resolution scan layer (0°): ±0.5°
Other 15 scan layers: ±1°
Scanning frequency 20Hz
Angular resolution Horizontal: 0.125° (2 high resolution scan layers) & 1° (14 scan
layers)
Vertical: approx. 2.5° and 5° see "Scan layer address", page 25.
Note: The actual position of a scan layer may differ.
The exact actual vertical angle value of each scan layer can be
read from the device.
Working range 0.05m ≤ x ≤ 60m
Scanning range for 10%
remission factor
10m @ 100kLux
12m @ 10kLux
Scanning range for 90%
remission factor
15m @ 100kLux
30m @ 10kLux
