Technical data
9.1 Motor starters
SIRIUS 3RM1 motor starter
114 Manual, 11/2013, A5E0345285095020A/RS-AB/002
3RM10..-.....
3RM11..-.....
3RM12..-.....
3RM13..-.....
Distance, to be maintained, to the ranks
assembly
• downwards
mm
50
• upwards
mm
50
• backwards
mm
0
• sidewards
mm
0
• forwards
mm
0
Distance, to be maintained, to earthed
part
• downwards
mm
50
• upwards
mm
50
• backwards
mm
0
• sidewards
mm
3.5
• forwards
mm
0
1)
You will find restrictions for operation from 40° C and also for operation above 1000 m in
the Chapter "Rated operational current and derating (Page 51)".
