Mounting
5.7 Disassembling the devices with device connectors from a standard mounting rail
SIRIUS 3RM1 motor starter
78 Manual, 11/2013, A5E0345285095020A/RS-AB/002
5.7
Disassembling the devices with device connectors from a standard
mounting rail
WARNING
Hazardous Voltage.
Can Cause Death, Serious Injury, or Property Damage.
Turn off and lock out all power supplying this device before working on this device.
Requirements
● The terminals have been removed or disconnected.
Procedure
Step
Operating instruction
Figure
1 Unlock the device using a screwdriver.
2
Pull the lower half of the device away from
the device connector.
3 Unlock the device using a screwdriver.
