Siemens 340 - Connection Cross Sections

Technical data
9.1 Motor starters
SIRIUS 3RM1 motor starter
Manual, 11/2013, A5E0345285095020A/RS-AB/002
123
9.1.6
Connection cross sections
Connectable cable cross-sections depend on the motor starter's connection system.
Connection system
Order number
Screw connection 3RM1...-1AA.4
Push-in spring-type terminals 3RM1...-2AA.4
Hybrid connection method
Control circuit realized as push-in spring-loaded
terminal and main circuit as screw terminal
3RM1...-3AA.4
The table below contains the suitable conductor cross-sections for the control circuit and
signaling contacts (= auxiliary contacts) and for the main circuit (= main contacts).
3RM1...-1....
3RM1...-2....
3RM1...-3....
Type of the connectable
conductor cross-section
• for main contacts
– solid
1x (0,5 ... 4 mm²),
2x (0,5 ... 2,5 mm²)
1x (0.5 ... 4 mm²) 1x (0,5 ... 4 mm²),
2x (0,5 ... 2,5 mm²)
– finely stranded
– with conductor end
processing
1x (0,5 ... 2,5 mm²),
2x (0,5 ... 1,5 mm²)
1x (0.5 ... 2.5 mm²) 1x (0,5 ... 2,5 mm²),
2x (0,5 ... 1,5 mm²)
– without conductor final
cutting
— 1x (0.5 ... 4 mm²) —
• for auxiliary contacts
– solid
1x (0,5 ... 2,5 mm²),
2x (1,0 ... 1,5 mm²)
1x (0.5 ... 1.5 mm²),
2x (0.5 ... 1.5 mm²)
1x (0.5 ... 1.5 mm²),
2x (0.5 ... 1.5 mm²)
– finely stranded
– with conductor end
processing
1x (0.5 ... 2.5 mm²),
2x (0.5 ... 1 mm²)
1x (0,5 ... 1,0 mm²),
2x (0,5 ... 1,0 mm²)
1x (0,5 ... 1,0 mm²),
2x (0,5 ... 1,0 mm²)
– without conductor final
cutting
— 1x (0.5 ... 1.5 mm²),
2x (0.5 ... 1.5 mm²)
1x (0.5 ... 1.5 mm²),
2x (0.5 ... 1.5 mm²)
• for AWG conductors
1)
– for main contacts
1x (20 ... 12),
2x (20 ... 14)
1x (20 ... 12) 1x (20 ... 12),
2x (20 ... 14)
– for auxiliary contacts
1x (20 ... 14),
2x (18 ... 16)
1x (20 ... 16),
2x (20 ... 16)
1x (20 ... 16),
2x (20 ... 16)
1)
All AWG data applies to solid conductors.
