Technical data
9.1 Motor starters
SIRIUS 3RM1 motor starter
116 Manual, 11/2013, A5E0345285095020A/RS-AB/002
Interference immunity of the 3RM11 and 3RM13 Failsafe motor starters
3RM11..-.....
3RM13..-.....
• Electrostatic discharge according to IEC 61000-4-2
6 kV contact discharge / 8 kV air discharge
• Conducted interference as high-frequency radiation
according to IEC 61000-4-6
10 V
Conductor-bound parasitic coupling BURST
according to
IEC 61000-4-4
3 kV / 5 kHz
• Conductor-bound parasitic coupling conductor-earth
SURGE according to IEC 61000-4-5
4 kV signal lines
2 kV
• Conductor-bound parasitic coupling conductor-conductor
SURGE according to IEC 61000-4-5
2 kV
