Siemens 7VK512

!PPENDIX6+
6

#
' #
Reference Table for Functional Parameters 7VK512
µµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµ
1000 PARAMETERS
1100 POWERSYSTEM DATA 3400
AUTO- RECLOSE FUNCTION
1103 Un PRIMARY 3401 AR FUNCT
min. 1 kV ON [ ]
max. 1200 ¬¬¬¬¬¬ OFF [ ]
1104 Un SECOND. 3403 MAN.CL.BL.
min. 80 V YES [ ]
max. 125 ¬¬¬¬¬¬ NO [ ]
1132 U1-U2ANGLE 3405 T-RECLAIM
min. -179 à min. 0.50 s
max. 180 ¬¬¬¬¬¬ max. 320.00 ¬¬¬¬¬¬
1133 T CB CLOSE 3406 TBLOCK DYN
min. 0.01 s min. 0.50 s
max. 0.50 ¬¬¬¬¬¬ max. 320.0/Ô ¬¬¬¬¬¬
1135 T CLOSE 3407 TBLOCK M/C
min. 0.01 s min. 0.50 s
max. 32.00 ¬¬¬¬¬¬ max. 320.00 ¬¬¬¬¬¬
3412 CB? 1 TRIP
2800 FAULT RECORDINGS YES [ ]
NO [ ]
2801 FAULT REC.
ON [ ] 3413 CB? CLOSE
OFF [ ] CB? NEVER [ ]
CB? WITH EACH AR [ ]
2802 INITIATION CB? WITH 2nd AR [ ]
BY FAULT DETEC. [ ]
BY TRIP <T-REC [ ] 3415 T-CB-SUPV
min. 0.01 s
2803 FAULT REC. max. 320.00 ¬¬¬¬¬¬
TO PC/PD [ ]
TO LSA [ ] 3419 SYN.CHK.PR
ONLY ARTER DAR [ ]
2804 T-REC AFTER 3POLE AR [ ]
min. 0.01 s AFTER 2nd DAR [ ]
max. 2.50 ¬¬¬¬¬¬ NEVER [ ]
3422 RAR PROGR.
THREE-POLE [ ]
SINGLE-POLE [ ]
SINGLE/THREE-POL [ ]
3424 RAR T-ACT
min. 0.01 s
max. 320.0/Ô ¬¬¬¬¬¬
