Operational Control Facilities 7VK512
µµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµµ
8000 DEVICE CONTROL 8514 COPY ? SET A -> SET B
8515 COPY ? SET A -> SET C
8100 SETTING REAL TIME CLOCK
8516 COPY ? SET A -> SET D
8101 DATE/TIME
8517 COPY ? SET B -> SET A
8102 DATE
8518 COPY ? SET B -> SET C
8103 TIME
8519 COPY ? SET B -> SET D
8104 DIFF. TIME
8520 COPY ? SET C -> SET A
8200 RESET 8521 COPY ? SET C -> SET B
8201 RESET LED ? 8522 COPY ? SET C -> SET D
8202 RESET COUNTERS ? 8523 COPY ? SET D -> SET A
8203 RESET TOTAL Isc ? 8524 COPY ? SET D -> SET B
8204 RESET OPERAT.ANNUNC. ? 8525 COPY ? SET D -> SET C
8205 RESET FAULT ANNUNC. ?
ON/OFF CONTROL
8500 PARAMETER CHANGE_OVER 2801 FAULT REC. ON
OFF
8501 ACTIV PARAM
3401 AR FUNCT ON
8503 ACTIVATION SET A OFF
SET B
SET C 3501 SYNC-CHECK ON
SET D OFF
Attention! With SYNC-CHECK = OFF no closing checks!
8510 COPY ? ORIG.SET->SET A
3521 SYN.MAN.CL ON
8511 COPY ? ORIG.SET->SET B OFF
Note: When 3501 is switched off, 3521 is off, too!
8512 COPY ? ORIG.SET->SET C
8513 COPY ? ORIG.SET->SET D
