Installation

88/214 Revision 11 • INSTALLATION AND OPERATING INSTRUCTIONS • 8DA10 • 861-9601.9

Assembly aid

Fig. 93: Example for an assembly aid (plank ① )

Fig. 92: Panel after removal of upper busbar housing system

WARNING

Risk of falling due to uncovered openings and cutouts

A cover prevents the person from falling into or through an opening or a cutout.

➭ Provide for sufficient load-bearing capacity of the cover.

➭ Provide for sufficient width of the cover.

➭ Secure the cover against shifting.
