Siemens Albatros2 Technical Manual

Engineering use
2
Operator units AVS74
15
Siemens Graphical User Interface UI400 CE1U2348en
Building Technologies 2014-06-03
Normally vertically mounted at the installation location (90°) on the producer
housing. The mounting surface may be inclined however.
The inclination is limited for AVS74.761 together with IP protection type (see next
section).
Device Protection standard to IEC 60529 Air tightness
AVS74.261
(with cover)
IP40
l Installed
No data
AVS74.261
(without cover)
IP40
l Installed
* Suitable for applications as per
EN 15502-2-1 with leakage rate ≥
0.4 m
3
/h at 0.5 mbar
AVS74.761
(with cover)
* IP44
l Installed
l All housing parts are
mounted
l Inclination: Deviation from
vertical ≤40°
* Suitable for applications as per
EN 15502-2-1 with leakage rate ≥
0.4 m
3
/h at 0.5 mbar
* See following note
The indicated degree of protection IP44 on the AVS74.761 and the indicated air
tightness on the AVS74.661 and AVS74.761, both require sealing of the mounting
housing and unit on the part of the customer.
Connection via cable AVS82.49x from controller.
Orientation
Protection against
foreign objects, water
protection, and air
tightness
Terminals
