44
Siemens Graphical User Interface UI400 CE1U2348en
Building Technologies 2014-06-03
5.2 Operating heating/cooling
Evaluation information
l The temperature page is sorted by living zones.
The living zone is displayed in the title for the work area.
l Separated by a dash, a summary of the present settings for the selected living
zone are displayed.
l The following is displayed at a maximum:
– Operating mode.
– Whether a temporary temperature adjustment (warmer, cooler) is active.
– Depending on the mode, the comfort setpoint for heating or the comfort
setpoint for cooling.
– The time program for the present day.
Temporary temperature adjustment and time program are available exclusively to
the Automatic operating mode.
Operating mode, temporary temperature adjustment, and time switch program
apply in common for heating and cooling. Only the comfort setpoint for heating or
cooling is displayed based on mode and can be set.
