43
Siemens Graphical User Interface UI400 CE1U2348en
Building Technologies 2014-06-03
Enter settings
l Select start page (
) on the navigation bar.
Settings:
l If changed to manual operating mode on the topic pages, it is reset to
Automatic mode with a single operating step.
l In the 'Off' position, the plant or zones are switched off. Energy consumption
is reduced to a minimum. The building or zones remain, however, protected
(e.g. in protection mode).
Proceed as follows to operate the plant/zone switch:
1. Turn the control knob and select the plant/zone switch.
2. Press the control knob.
The plant-zone switch setting (e.g. Automatic) is selected and is displayed
inverted.
3. Press the control knob and select the desired setting (Automatic or Off).
4. Press the control knob to activate the setting.
a The entire plant or assigned zones are set to Automatic mode or off as a group.
The hand symbol " " alongside the plant/zone switch and on the status bar
indicates that the operating modes on the topic pages are set to manual.
Prerequisites
Operate plant/zone
switch
