78
Siemens Graphical User Interface UI400 CE1U2348en
Building Technologies 2014-06-03
8.2.1 Complete parameter list
Structure and design of the parameter list
The complete parameter list has the following structure:
l The title of the parameter list page is a technology topic (e.g. heating circuit 1)
for the plant encompassing multiple parameters (operating line).
l 3 operating lines are displayed per parameter list page. "Current page of total"
is displayed to the right of the title if a title includes more than 3 operating lines.
l You can scroll through the parameter list pages on highlighted page titles; left
for topics, right within a topic.
l The operating line numbers are sorted chronologically in ascending order via
topics and pages.
l The user's guide for your controller includes an overview table and detailed
explanations on all parameters.
A long press of the knob (> 3 seconds) jumps from any page to the "Expert view
start page" (diagnostics page).
