AOP Operating Instructions – Issue 07/05
6SE6400-5AP00-0BB0
Options Description
OPERATE Displays the current status of the inverter/motor.
DIAGNOSTICS Displays a recent fault history.
PARAMETERS
Allows the user to configure individual parameters or
parameter groups for specific applications.
MODE
Allows the user to select the AOPs mode of operation as
follows:
LOCAL
MASTER
INTERNAL
SLAVE
PC Mode
MM3 Upload
UPREAD
Allows the user to read a parameter set from the inverter
into the AOP.
DOWNLOAD Allows the user to write a parameter set to the inverter.
LANGUAGE
Allows the user to select a new language for the AOP
display.
SETUP
Allows the user to personalize the configuration of the
AOP.
TIMER
Allows the user to set a start and stop time for the
inverters operation.
Press the and simultaneously, at any time will return the user to
the main menu.
3.6 Wait Request
Some operations that the inverter is requested to perform may take some time
to complete.
A screen (an example is shown below) is displayed to inform the user that the
AOP is waiting for the inverter to complete a task.
