27
AOP Operating Instructions – Issue 07/05
6SE6400-5AP00-0BB0
To access the Setup menu the following procedure should be performed:
1. From the Main Menu scroll through the list of options using the
and
keys until ‘SETUP’ is highlighted.
2. Press the
key to confirm the selected option.
The user is then presented with the setup menu:
3. Using the
and keys scroll through the list until the required
option is highlighted.
4. Press the
key to confirm the selected option.
Pressing the
and keys simultaneously, at any time will display the
relevant help screens to assist the user.
7.1.1 Backlighting
To activate the backlighting option on the AOP, the following procedure should
performed:
1. Using the
and keys select the ‘Backlighting’ option from the
Setup menu.
2. Press
to confirm the selection.
The user is then presented with the Backlighting screen.
3. Using the
and keys select either the off or on state.
4. Press
to confirm the selected function.
The backlighting function can be set to switch off the backlighting after a specific
period of time (in seconds) of inactivity.
5. Using the
and keys select the timing function.
6. Press
to set the time delay screen.
7. Using the
and keys set the required time.
8. Press
to confirm the action and return to the Setup menu.
Pressing the and keys simultaneously, at any time will display
the relevant help screens to assist the user.
