When testing is complete, an internal thermal printer prints the test results.
Figure
2
User
Interface,
T
esting
and
Printing Ar
eas
Connections and Power
The line cord is connected into
the line cord receptacle. Turn the analyzer on
by pressing the power switch
to the on
position. Y
ou can connect a
computer
,
printer
, ethernet connection, keyboard, and
handheld barcode reader to
the
analyzer using the interface connectors.
1
Display
2
Printer
3
Waste bin
4
Fixed platform
5
Incubation/read station
6
Strip loading station
7
Push bar
