S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
A5E00105492-03
9-27
*6')LOHV
If you are working on an IM 308-C or third party system, you require a GSD file in
order to be able to configure the DP CPU as a DP slave in a DP master system.
&20352),%86 as of V 4.0 includes this GSD file.
When working with an older version or another configuration tool, you can
download the GSD file under:
• Internet URL http://www.ad.siemens.de/csi/gsd
or
• via modem from the 66&(Interface &HQWHU Fürth, Germany; Phone number
(0911) 737972.
1RWH
This note is applicable to CPU 31xC-2 DP, CPU 315-2 DP, and CPU 317-2 DP. If
you wish to use the CPU as a standard slave via the GSD file, then you must not
tick the Commissioning / Test mode check box under the DP interface properties
when you configure this slave CPU in STEP 7.
&RQILJXUDWLRQDQGSDUDPHWHUDVVLJQPHQWPHVVDJHIUDPH
67(3 assists you during configuration and parameter assignment of the DP
CPU. Should you require a description of the configuration and parameter
assignment frame, in order to use a bus monitor for example, you can find it on the
Internet at http://www.ad.siemens.de/csinfo under article ID 1452338.
&RPPLVVLRQLQJ
Commission the DP CPU as a DP slave in the PROFIBUS subnet as follows:
1. Switch on power, but hold the CPU in STOP mode.
2. First, switch on all other DP masters/slaves.
3. Now switch the CPU to RUN mode.
6WDUWXSRI'3&38DVD'3VODYH
When the DP-CPU is switched to RUN mode, two mutually independent operating
mode transitions are executed:
• The &38 switches from STOP to RUN mode.
• At the 352),%86'3LQWHUIDFH the CPU starts data transfer with the DP
master.

Siemens CPU 315-2 DP Specifications

General

Memory	64 KB
Power Supply	24 V DC
Order Number	6ES7 315-2AG10-0AB0
Number of DP Masters	1
Number of DP Slaves	124
Load Memory	64 KB
Number of Timers	256
Number of Counters	256
Data Memory	64 KB
Operating Temperature	0 to 60 °C
Integrated Interfaces	MPI, DP
Digital Outputs	Not integrated
Analog Inputs	Not integrated
Analog Outputs	Not integrated
Programming Languages	LAD, FBD, STL
Digital Inputs	Not integrated
Weight	660 g
