Siemens CPU 315-2 DP Hardware And Installation Guide

$SSHQGL[
S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
A5E00105492-03
12-9
 ([DPSOHVRIDQ(0&&RPSDWLEOH,QVWDOODWLRQ
,QWURGXFWLRQ
Below you can find two examples of an EMC compatible PLC installation.
6DPSOH(0&FRPSDWLEOHFDELQHWLQVWDOODWLRQ
The figure below shows a cabinet installation with the measures described above
(bonding of inactive metal parts to chassis ground and connecting the cable
shielding to ground). This sample applies only to grounded operation. Note the
points in the figure when you install your system.
1
2
3
4
5
6
7
8
Figure 12-2 Example of an EMC compatible cabinet installation

Siemens CPU 315-2 DP Specifications

General

Memory	64 KB
Power Supply	24 V DC
Order Number	6ES7 315-2AG10-0AB0
Number of DP Masters	1
Number of DP Slaves	124
Load Memory	64 KB
Number of Timers	256
Number of Counters	256
Data Memory	64 KB
Operating Temperature	0 to 60 °C
Integrated Interfaces	MPI, DP
Digital Outputs	Not integrated
Analog Inputs	Not integrated
Analog Outputs	Not integrated
Programming Languages	LAD, FBD, STL
Digital Inputs	Not integrated
Weight	660 g
