S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
A5E00105492-03
5-17
6SHFLILHGFRPSRQHQWVDQGSURWHFWLYHPHDVXUHV
A number of components and protective measures are prescribed for plant
installations. The type of components and the degree of compulsion pertaining to
the protective measures will depend on the VDE specification applicable to your
particular plant.
The table below shows components and protective measures.
Table 5-7 VDE specifications for the installation of a PLC system
&RPSDUH  9'( 9'(
Disconnecting devices for
control systems, sensors
and actuators
(1) ... Part 460:
Master switch
... Part 1:
Circuit breaker
Short-circuit/overload
protection:
In groups for sensors and
actuators
(2) ... Part 725:
Single-pole fusing of
circuits
... Part 1:
• In the case of a grounded
secondary circuit: Provide
single-pole protection
• Otherwise: Provide all-
pole protection
Load power supply for AC
load circuits with more than
five electromagnetic devices
(3) Electrical isolation by
transformer
recommended
Electrical isolation by
transformer mandatory
1) This column refers to the numbers in the diagram in the Summary diagram: Grounding
section.
&URVVUHIHUHQFH
Additional information on protective measures is in the Appendix.
VHHDOVR
General Rules and Regulations for S7-300 Operation

Siemens CPU 315-2 DP Specifications

General

Memory	64 KB
Power Supply	24 V DC
Order Number	6ES7 315-2AG10-0AB0
Number of DP Masters	1
Number of DP Slaves	124
Load Memory	64 KB
Number of Timers	256
Number of Counters	256
Data Memory	64 KB
Operating Temperature	0 to 60 °C
Integrated Interfaces	MPI, DP
Digital Outputs	Not integrated
Analog Inputs	Not integrated
Analog Outputs	Not integrated
Programming Languages	LAD, FBD, STL
Digital Inputs	Not integrated
Weight	660 g
