S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
A5E00105492-03
5-37
:KLFKGHYLFHVFDQ,FRQQHFWWRZKLFKLQWHUIDFH"
Table 5-17 The following devices may be connected
03, 352),%86'3 3W3
• PG/PC
• OP/TP
• S7-300/400 with MPI
interface
• S7-200
(19.2 Kbps only)
• PG/PC
• OP/TP
• DP slaves
• DP master
• Actuators/Sensors
• S7-300/400 with
PROFIBUS-DP
interface
• Devices equipped with a
serial port, e.g. barcode
readers, printers, etc.
)XUWKHULQIRUPDWLRQ
Further information on specific connections can be found in the &RPPXQLFDWLRQ
ZLWK6,0$7,& manual.
Details on PtP communication is found in the 7HFKQRORJLFDO)XQFWLRQV Manual.

Siemens CPU 315-2 DP Specifications

General

Memory	64 KB
Power Supply	24 V DC
Order Number	6ES7 315-2AG10-0AB0
Number of DP Masters	1
Number of DP Slaves	124
Load Memory	64 KB
Number of Timers	256
Number of Counters	256
Data Memory	64 KB
Operating Temperature	0 to 60 °C
Integrated Interfaces	MPI, DP
Digital Outputs	Not integrated
Analog Inputs	Not integrated
Analog Outputs	Not integrated
Programming Languages	LAD, FBD, STL
Digital Inputs	Not integrated
Weight	660 g
