S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
A5E00105492-03
11-1
7HVWLQJ)XQFWLRQV'LDJQRVWLFVDQG)DXOW(OLPLQDWLRQ

 ,QWKLV&KDSWHU
,QWURGXFWLRQ
This Chapter helps you to get acquainted with tools you can use to carry out the
following tasks:
Hardware/software error diagnostics.
Elimination of hardware/software errors.
Testing the hardware/software - for example, during commissioning.
1RWH
It would go beyond the scope of this manual to provide detailed descriptions of all
the tools you can use for diagnostics, testing and troubleshooting functions.
Further notes are found in the relevant hardware/software manuals.
 2YHUYLHZ7HVWLQJ)XQFWLRQV
6RIWZDUHWHVWLQJIXQFWLRQV0RQLWRULQJDQGPRGLI\LQJRIYDULDEOHVVLQJOHVWHS
PRGH
STEP 7 offers you the following testing functions you can also use for diagnostics:
Monitoring and modifying of variables
Can be used for PG/PC monitoring of specific CPU or user program variables.
You can also declare permanent values for the variables.
Testing with program status
You can test your program by viewing the program status of each function
(result of logical links, status bit) or the data of specific registers in real-time
mode.
For example, if you have selected the programming language LAD in STEP 7
for your presentation, the color of the symbol will indicate a closed switch or an
active circuit.

Table of Contents

Other manuals for Siemens CPU 315-2 DP

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Siemens CPU 315-2 DP and is the answer not in the manual?

Siemens CPU 315-2 DP Specifications

General IconGeneral
Memory64 KB
Power Supply24 V DC
Order Number6ES7 315-2AG10-0AB0
Number of DP Masters1
Number of DP Slaves124
Load Memory64 KB
Number of Timers256
Number of Counters256
Data Memory64 KB
Operating Temperature0 to 60 °C
Integrated InterfacesMPI, DP
Digital OutputsNot integrated
Analog InputsNot integrated
Analog OutputsNot integrated
Programming LanguagesLAD, FBD, STL
Digital InputsNot integrated
Weight660 g
