Siemens CPU 315-2 DP Hardware And Installation Guide

&RQILJXULQJ
S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
5-12 A5E00105492-03
6SHFLILFDWLRQVIRUFDELQHWGLPHQVLRQV
Note the following specifications when you determine the dimensions of a cabinet
suitable for an S7-300 installation:
• Space required for racks (rails)
• Minimum clearance between the racks and cabinet walls
• Minimum clearance between the racks
• Space required for cable ducts or fans
• Position of the stays
:DUQLQJ
Modules may get damaged if exposed to inadmissible ambient temperatures.
5HIHUHQFHIRUDPELHQWWHPSHUDWXUHV
Information on permissible ambient temperatures is in the Appendix: see $PELHQW
&RQGLWLRQV

Siemens CPU 315-2 DP Specifications

General

Memory	64 KB
Power Supply	24 V DC
Order Number	6ES7 315-2AG10-0AB0
Number of DP Masters	1
Number of DP Slaves	124
Load Memory	64 KB
Number of Timers	256
Number of Counters	256
Data Memory	64 KB
Operating Temperature	0 to 60 °C
Integrated Interfaces	MPI, DP
Digital Outputs	Not integrated
Analog Inputs	Not integrated
Analog Outputs	Not integrated
Programming Languages	LAD, FBD, STL
Digital Inputs	Not integrated
Weight	660 g
