Siemens CRT

Matrix Switching Systems
Matrix Switchers
10-7© Siemens Building Technologies Group
10
Type Order No.
SIMATRIX NEO 32x8
Matrix Switching System 32x8‚ Preconf.‚ Expandable
As SIMNEO Preconf.. for technical details‚ but with the following differ-
ences:
Camera inputs 32 x
Monitor output 8 x
Interfaces SysLink for communication with
SIMNEO-EXT and SIMNEO-A128
Alarm connector 2 x 37-pin Sub-D-Female connector
Alarm inputs 32 x‚ max 256 with SIMNEO-A128
Design 19-inch rack mountable; 6 U
Dimensions (W x H x D) 441 x 266 x 217 mm‚ 19''‚ 6 U
Weight 6.74 kg
2GF2211-8JA
SIMATRIX NEO 64x8
Matrix Switching System 64x8‚ Preconf.‚ Expandable
As SIMNEO Preconf.. for technical details‚ but with the following differ-
ences:
Camera inputs 64 x
Monitor output 8 x
Interfaces SysLink for communication with
SIMNEO-EXT and SIMNEO-A128
Alarm connector 2 x 37-pin Sub-D-Female connector
Alarm inputs 32 x‚ max 256 with SIMNEO-A128
Design 19-inch rack mountable; 6 U
Dimensions (W x H x D) 441 x 266 x 217 mm‚ 19''‚ 6 U
Weight 7.22 kg
2GF2211-8JB
SIMATRIX NEO 96x8
Matrix Switching System 96x8‚ Preconf.‚ Expandable
As SIMNEO Preconf.. for technical details‚ but with the following differ-
ences:
Camera inputs 96 x
Monitor output 8 x
Interfaces SysLink for communication with
SIMNEO-EXT and SIMNEO-A128
Alarm connector 2 x 37-pin Sub-D-Female connector
Alarm inputs 32 x‚ max 256 with SIMNEO-A128
Design 19-inch rack mountable; 6 U
Dimensions (W x H x D) 441 x 266 x 217 mm‚ 19''‚ 6 U
Weight 7.70 kg
2GF2211-8JC
SIMATRIX NEO 128x8
Matrix Switching System 128x8‚ Preconf.‚ Expandable
As SIMNEO Preconf.. for technical details‚ but with the following differ-
ences:
Camera inputs 128 x
Monitor output 8 x
Interfaces SysLink for communication with
SIMNEO-EXT and SIMNEO-A128
Alarm connector 2 x 37-pin Sub-D-Female connector
Alarm inputs 32 x‚ max 256 with SIMNEO-A128
Design 19-inch rack mountable; 6 U
Dimensions (W x H x D) 441 x 266 x 217 mm‚ 19''‚ 6 U
Weight 8.18 kg
2GF2211-8JD
