Siemens CRT

Matrix Switching Systems
Matrix Switchers
10-8 © Siemens Building Technologies Group
Type Order No.
SIMATRIX NEO 16x16
Matrix Switching System 16x16‚ Preconf.‚ Expandable
As SIMNEO Preconf.. for technical details‚ but with the following differ-
ences:
Camera inputs 16 x
Monitor output 16 x
Interfaces SysLink for communication with
SIMNEO-EXT and SIMNEO-A128
Alarm connector 2 x 37-pin Sub-D-Female connector
Alarm inputs 32 x‚ max 256 with SIMNEO-A128
Design 19-inch rack mountable; 6 U
Dimensions (W x H x D) 441 x 266 x 217 mm‚ 19''‚ 6 U
Weight 6.53 kg
2GF2211-8KA
SIMATRIX NEO 32x16
Matrix Switching System 32x16‚ Preconf.‚ Expandable
As SIMNEO Preconf.. for technical details‚ but with the following differ-
ences:
Camera inputs 32 x
Monitor output 16 x
Interfaces SysLink for communication with
SIMNEO-EXT and SIMNEO-A128
Alarm connector 2 x 37-pin Sub-D-Female connector
Alarm inputs 32 x‚ max 256 with SIMNEO-A128
Design 19-inch rack mountable; 6 U
Dimensions (W x H x D) 441 x 266 x 217 mm‚ 19''‚ 6 U
Weight 6.77 kg
2GF2211-8KB
SIMATRIX NEO 64x16
Matrix Switching System 64x16‚ Preconf.‚ Expandable
As SIMNEO Preconf.. for technical details‚ but with the following differ-
ences:
Camera inputs 64 x
Monitor output 16 x
Interfaces SysLink for communication with
SIMNEO-EXT and SIMNEO-A128
Alarm connector 2 x 37-pin Sub-D-Female connector
Alarm inputs 32 x‚ max 256 with SIMNEO-A128
Design 19-inch rack mountable; 6 U
Dimensions (W x H x D) 441 x 266 x 217 mm‚ 19''‚ 6 U
Weight 7.25 kg
2GF2211-8KC
SIMATRIX NEO 96x16
Matrix Switching System 96x16‚ Preconf.‚ Expandable
As SIMNEO Preconf.. for technical details‚ but with the following differ-
ences:
Camera inputs 96 x
Monitor output 16 x
Interfaces SysLink for communication with
SIMNEO-EXT and SIMNEO-A128
Alarm connector 2 x 37-pin Sub-D-Female connector
Alarm inputs 32 x‚ max 256 with SIMNEO-A128
Design 19-inch rack mountable; 6 U
Dimensions (W x H x D) 441 x 266 x 217 mm‚ 19''‚ 6 U
Weight 7.73 kg
2GF2211-8KD
