Siemens CRT

Matrix Switching Systems
Matrix Switchers
10-9© Siemens Building Technologies Group
10
Type Order No.
SIMATRIX NEO 128x16
Matrix Switching System 128x16‚ Preconf.‚ Expandable
As SIMNEO Preconf.. for technical details‚ but with the following differ-
ences:
Camera inputs 128 x
Monitor output 16 x
Interfaces 8 x TTY-(20mA) for CKAs‚ 16 x SCU-
(20mA)-Interface for CDC
Alarm connector 2 x 37-pin Sub-D-Female connector
Alarm inputs 32 x‚ max 256 with SIMATRIX NEO-
A128
Design 19-inch rack mountable; 6 U
Dimensions (W x H x D) 441 x 266 x 217 mm‚ 19''‚ 6 U
Weight 8.21 kg
2GF2211-8KE
SIMATRIX NEO 160x16
Matrix Switching System 160x16‚ Preconf.‚ Expandable
As SIMNEO Preconf.. for technical details‚ but with the following differ-
ences:
Camera inputs 160 x
Monitor output 16 x
Interfaces SysLink for communication with
SIMNEO-EXT and SIMNEO-A128
Alarm connector 2 x 37-pin Sub-D-Female connector
Alarm inputs 64 x‚ max 256 with SIMNEO-A128
Design 2 x 19-inch rack mountable; 12 U
Dimensions (W x H x D) 441 x 532 x 217 mm‚ 19''‚ 12 U
Weight 15.02 kg
2GF2211-8KF
SIMATRIX NEO 224x16
Matrix Switching System 224x16‚ Preconf.‚ Expandable
As SIMNEO Preconf.. for technical details‚ but with the following differ-
ences:
Camera inputs 224 x
Monitor output 16 x
Interfaces SysLink for communication with
SIMNEO-EXT and SIMNEO-A128
Alarm connector 2 x 37-pin Sub-D-Female connector
Alarm inputs 64 x‚ max 256 with SIMNEO-A128
Design 2 x 19-inch rack mountable; 12 U
Dimensions (W x H x D) 441 x 532 x 217 mm‚ 19''‚ 12 U
Weight 15.98 kg
2GF2211-8KG
SIMATRIX NEO 32x32
Matrix Switching System 32x32‚ Preconf.‚ Expandable
As SIMNEO Preconf.. for technical details‚ but with the following differ-
ences:
Camera inputs 32 x
Monitor output 32 x
Interfaces SysLink for communication with
SIMNEO-EXT and SIMNEO-A128
Alarm connector 2 x 37-pin Sub-D-Female connector
Alarm inputs 32 x‚ max 256 with SIMNEO-A128
Design 19-inch rack mountable; 6 U
Dimensions (W x H x D) 441 x 266 x 217 mm‚ 19''‚ 6 U
Weight 6.83 kg
2GF2211-8LA
