Matrix Switching Systems
Accessories Matrix Switching Systems
10-15© Siemens Building Technologies Group
10
Type Order No.
VC-ALARM
VC-Alarm Visilynx 3 Alarm-Cable
Visilynx 3 alarm cable
Dimensions (W x H x D) Length 1 m
Weight 0.24 kg
BPZ:80-230
VC-PCCON
VC-PCCON Visilynx 3 PCCON Cable
The PCCON cable is used to interface the Visilynx 3 to a PCCON control
device.
Dimensions (W x H x D) Length 1 m
Weight 0.18 kg
BPZ:80-222
VC-3CONFIG
VC-3CONFIG Visilynx 3 Conf.-Cable
Weight 0.70 kg
BPZ:80-227
V3-QUAD
Visilynx 3 Colour Quad-Module
Displays four‚ high-resolution colour pictures on a single Visilynx 3 vid-
eo output in real time‚ with each segment controllable from the Visilynx
keyboard as a separate monitor number. Will display the inputs in quad
format in a specified order‚ or any one input as full-screen. One or two
quad cards can be fitted in a Visilynx 3 Integrated System Unit (V3-ISU)‚
separate composite and S-Video outputs are available on the rear pan-
el. Each segment can be independently frozen. Time-base correction of
video inputs ensures high quality pictures without the need for external
camera synchronisation. Each picture segment is frozen when the
source input is switched‚ in both full-screen and quad mode‚ to prevent
picture roll. All the inputs have AGC to preserve clear images independ-
ent of differences in picture levels. Colour text insertion on the monitor
output. Self-test fault diagnostics.
Inputs 4 from the 16 available from the
Visilynx Integrated System Unit.
Inputs time-base corrected and with
AGC.
Outputs Separate Composite and S-Video
outputs available. Will display 4
inputs in quad format in a specified
order‚ or any 1 input as full-screen.
Each segment can be independent-
ly frozen.
Dimensions (W x H x D) 220 x 100 mm
3U Visilynx 3 Euro card
Weight 0.140 kg
BPZ:80-226
