Cameras and Domes
Fixed Domes
1-31© Siemens Building Technologies Group
1
Type Order No.
CVVC1315..
1/3" CCD 3-8 mm Colour Vandal Resistant Varifocal Dome‚ 480 TVL‚
12 V DC / 24 V AC
Attractive‚ vandal resistant‚ high resolution colour camera with IP66
protection rating‚ for either ceiling or wall mount‚ complete with 1000
kg impact-resistant‚ polycarbonate protective bubble. Specifically
designed to withstand the type of physical abuse and random vandal-
ism encountered in public areas‚ both outdoor‚ and indoor‚ and includes
service monitor connection and cable for local‚ easy setup and external‚
anti-tamper fixing screws.
Horizontal resolution 480 TV lines
Minimum illumination 0.47 Lux (F1.0 @50IRE)
Gain control AGC (ON/OFF)
S/N ratio > 50 dB
Lens 3 D 8 mm‚ DD auto-iris‚ aspherical
Electronic shutter (AES) Autom 1/50 to 1/100K s
Horizontal angle of view 36 D 91º
Minimum object distance 0.2 m
Bubble type Tinted
Backlight compensation (ON/OFF)
Local service monitor connector 2-pin (1 m cable included)
Dimensions (W x H) 140 x 112 mm
Power consumption 3.5 W
Power requirements 12 V DC / 24 V AC
Weight 1.7 kg
CVVC1315..
CVVC1315-LP
1/3" CCD Colour Vandal Resistant Varifocal Dome‚ 480 TVL PAL‚
12 V DC / 24 V AC
As CVVC1315.. for technical details‚ but with the following differences:
Television standard PAL: 625 lines‚ 50 fields‚
50 Hz (vertically)‚
15.625 Hz (horizontally)
Pixels 752 (H) x 582 (V)
2GF1185-8AA
CVVC1315-LN
1/3" CCD Colour Vandal Resistant Varifocal Dome‚ 480 TVL NTSC‚
12 V DC / 24 V AC
As CVVC1315.. for technical details‚ but with the following differences:
Television standard NTSC: 525 lines‚ 60 fields‚
60 Hz (vertically)‚
15.734 Hz (horizontally)
Pixels 768 (H) x 494 (V)
2GF1185-8AB
