Periphery board (500p) FCI2017
2
29 |
Building Technologies
Element Des. Function
Jumpers X403 DEGRADE ALARM SILENCEABLE/NONSILENCEABLE
X602 DEGRADED MODE ENABLE/DISABLE for NAC 1 class A or NAC 1-1 class B
X603 DEGRADED MODE ENABLE/DISABLE for NAC 1-2 class B
X604 NAC 1 class A/B selection
X605 NAC 1 class A/B selection
X606 NAC 1 class A/B selection
X305 Power supply 2 ON/OFF
Connector X201 PMI & mainboard bus
X202 Peripheral data bus output
X204 Future expansion
X301 Connector for power supply 1 (PS1)
X302 Connector plug for power supply 2 (PS2) in housing (3HU)
X303 Battery connection
X304
DC 24 V connection to Card Cage VCA2002 for feed to the voice alarm modules and
associated peripherals
X601 NAC1 output
X801 Bell follower input
X901 NAC 2 expansion or releasing module
X902 Leased line / city tie module
X1001 Auxiliary DC 24 V output
X1101 Common alarm relay positions 1…3
Common trouble relay positions 4…6
Common supervisory relay positions 7…9
User programmable relay positions 10…12
X1302 For future applications
X1401 Detector circuit core A, circuit 1
X1402 Detector circuit core A, circuit 2
X1702 For future applications
X1801 Detector circuit core B, circuit 3
X1802 Detector circuit core B, circuit 4
