Siemens FCI2016-U1

Periphery board (500p) FCI2017
Detector circuits, circuit driver 1 (circuits 1 and 2) and circuit driver 2 (circuits 3 and 4)
2
40 | 46
Building Technologies
A6V10315038_f_en_
--
Siemens Industry, Inc.
2016
-
02
-
25
2.9.2 X1401 and X1801 terminal block – detector circuits 1 and 3
X1401: Circuit driver 1, circuit 1
X1801: Circuit driver 2, circuit 3
Pin Designation Description
1 2- Return feed for circuit 1-2 or circuit 3-2
2 2+ Positive output for circuit 1-2 or circuit 3-2
3 1- Return feed for circuit 1-1 or circuit 3-1
4 1+ Positive output for circuit 1-1 or circuit 3-1
Admissible cable cross-section: 1 x 12…18 AWG or 2 x 16…18 AWG
2.9.3 X1402 and X1802 terminal block – detector circuits 2 and 4
X1401: Circuit driver 1, circuit 2
X1801: Circuit driver 2, circuit 4
Pin Designation Description
1 2- Return feed for circuit 2-2 or circuit 4-2
2 2+ Positive output for circuit 2-2 or circuit 4-2
3 1- Return feed for circuit 2-1 or circuit 4-1
4 1+ Positive output for circuit 2-1 or circuit 4-1
Admissible cable cross-section: 1 x 12…18 AWG or 2 x 16…18 AWG
