2.10 Indicators
Standard LED indicators
LED Color Condition Meaning
H1301 Yellow OFF Default
ON
Startup problems FDnet/C-NET core A
(clock)
1 flash every 2 seconds Failsafe active (no communication to PMI)
2 fast flashes (every 2 seconds) Failsafe active + local alarm
1 fast flash (every 1 second) Failsafe active + signaling (local alarm)
Flash (every 1 second) and 2 fast flashes
(every 2 seconds)
Failsafe active + local alarm + signaling
H1701 Yellow OFF Default
ON
Startup problems FDnet/C-NET core B
(clock)
1 flash every 2 seconds Failsafe active (no communication to PMI)
2 fast flashes (every 2 seconds) Failsafe active + local alarm
1 fast flash (every 1 second) Failsafe active + signaling (local alarm)
Flash (every 1 second) and 2 fast flashes
(every 2 seconds)
Failsafe active + local alarm + signaling
2.11 Reset Buttons
2.11.1 S100 RESET periphery board
Button Function Position Meaning
S100
Reset main microprocessor on
periphery board
Not pressed Normal
Pressed
Resets only the main
microprocessor on the periphery
board.
