2.3 Views
Figure 8: Printed circuit board view for FCI2017
Element Des. Function
Fuses F301 30 A fuse for battery
F302 Fuse 20 A for voice alarm DC 24 V output
LEDs H1301 Status indicator for detector core A (circuits 1 and 2)
H1701 Status indicator for detector core B (circuits 3 and 4)
Reset buttons S100
Reset button for microprocessor for periphery board circuitry (not including detector
circuits)
12
X801
X901
F301
X303
X304
X301
X202
X1101
X1802
X1402
X1401 X1801
X1702
X201
X1001
X902
X204
X1302
S100
H1301
H1701
X601
X403
X305
1
1
11
1
11
1
1
1
1 1
1
1
1
1
1
1
3
1
1
3
1 6
7
1
X603
X602
X605
X606
X604
X302
F302
