Once all events are acknowledged and audibles silenced, a Reset System soft key
becomes available in the lower right side of the display. If notification appliances were
active, two additional soft keys become available at the bottom of the screen. These
allow the operator to silence or unsilence the notification appliances (audibles). When
the notification appliances are silenced the Audibles Silenced LED lights.
Press the More Info/+ button to display a screen showing details relating to the
selected event. Additional soft keys appear at the bottom of this screen, including one
that displays a map of the area in which the event occurred, provided this information
has been programmed using the Zeus tool. The operator can return to the previous
screen by pressing the (-) button, which is adjacent to the More Info/+ button.
Event counts in PMIs and SSDs may differ because SSDs currently display only
“primitive” (individual) events, while a group PMI whose devices are programmed
into groups in Zeus will display only one queue event per group.
Alarm When an alarm is detected, the red Alarm LED blinks, the System’s internal audible
sounds steady, the Audibles On LED glows steady, and the alarm event displays on the
screen with a blinking exclamation mark (!) See Figure 1-6. The event listing displays the
Event Custom Message, the Time of the event occurrence and the Alarm Event
Category (refer to the Alarm Event: Category Cross Reference Table.
Alarms 1
Supers 1
Securities 1
Troubles 1
First Floor Reception Area
Alarm Event CATEGORY
10:53
IN
(This Area Currently Not Used)
Acknowledge
Alarms
Silence
Audibles
Unsilence
Audibles
Reset
System
ACTIVE
ACK’D
ALARM
IN
IN
Figure 1-6
Alarm Event Screen
ECNEREFER-SSORCYROGETAC:TNEVEMRALA
yrogetaCeciveDlacisyhP
EKOMSMZH,11-PFH
TAEHtupnI61-MIS,MZH,IRTH,11-TPFH
LAUNAMMZH,tupnI61-MIS,IRTH,SMH
ENOZ.VNOC)enozlanoitnevnocanoegasueciveddeximrof(MZH
WOLFRETAW61-MIS,MZH,IRTH
noitacilppaehtnodesab,srehtorofelbatcelesdnasecivedemosrofdexiferaseirogetaC:ETON
).elbatcelessiIRTHtub,LAUNAMsyawlasiSMH,.e.i(.lootgnimmargorpsueZehtnidetceles
