PMI OPERATION MANUAL | CHAPTER 3
MAINTENANCE MODE3-4
Using The Disarm Feature Navigate to the desired device (Physical View) or group (Geographic View) using the
More Info+/- buttons, select the Control option by pressing the Control soft key and
then “Touch” the box labeled Disarm.
The Disarm Devices screen displays showing the location. See Figure 3-4.
In this example, AT: FireFinder-XLS@1, DLC@1, HFP11@2, where:
• FireFinder@1—Node 1 of the FireFinder System
• DLC@1—the DLC module at address 1
• HPF11@2—the HFP-11 detector at device address 2
Menu:Maint:Control:Disarm
PHY: @1FireFinder , DLC@1, HFP11@2
Cancel Settings Execute
DISARM DEVICES
OUTPUT: De-Energized
AT: FireFinder-XLS@1, DLC@1, HFP11@2
Figure 3-4
Maintenance: Control: Disarm Devices Screen
To disarm all elements associated with the device, press the Execute soft key.
To select individual components associated with the device, press the Settings soft key.
Touch the desired Devices, Inputs or Outputs box to select it. See Figure 3-5. This
screen is context-sensitive and will allow you to select only those items which are
applicable. (If you select the wrong item, touch the box you wish to select.)
Apply To
Output
Menu:Maint:Control:Disarm:Settings
PHY:FireFinder@1, DLC@1, HFP11@2
Cancel OK
Inputs
De-Energized
Devices
Energized
Outputs
Figure 3-5
Maintenance:Control Mode: Disarm Settings
