OTHER MODES 4-1
FUNCTION KEYS If Functions keys have been programmed in the Zeus tool, they can be accessed in
the Menu mode by pressing the Function soft key. The Function Key status screen
appears with a listing of all the functions. See Figure 4-1. To perform a desired
function, highlight the function using the up and down arrow keys and then press
the Execute soft key.
Function keys are momentary. If you want the associated outputs to be maintained,
use a latching function when you design logic in the Zeus programming tool.
Menu:Function Keys
FireFinder@1
Cancel
Page Up ExecutePage Down
F1 Function Key@address 253:1
F2 Function Key@address 253:2
F3 Function Key@address 253:3
Figure 4-1
Selecting Function Keys
LOGOUT Use the logout feature to leave the password protected area. Press the Logout soft
key to log out of Control mode. The Logout label grays out and the lit green triangle
turns off to indicate that logout is completed. See Figure 4-2.
